Why to simplify?
The decision to suppress or preserve geometry strongly depends on the analysis context and the application types.
For example, holes, fillets, and chamfers often do not significantly affect the analysis results.
Presence of small geometrical details influence size of the FEM model.
(number of elements is getting high)
Meshing issues - due to topological issues meshing process cannot be accomplished
Presence of wrong topology can lead to creation of highly distorted elements, which affects solution stability and accuracy.
Table of Content
Part 1. Introduction to Geometry concept
Part 2. Simplification process of 3D Solids
Part 3. NFX Simplification tools overview
Part 4. Challenges and obstacles
Speaker : Piotr Stepien
Category : Mechanical
Software : midas NFX
Date : 2019-03-26
