Midas GTS NX: TBM in Soft Soil

Underground , Tunnel , Wall , Excavation , Consolidation , midas GTS NX .

A super quick read.

Author: Angel Francisco Martinez

Publish Date: 27 Dec, 2021

This webinar showed how to use the Finite Element Method (FEM) to simulate the staged construction of a tunnel by a Tunnel Boring Machine (TBM) in soft soil. The tunnel support system has double lining, prefabricated segments and sliding formwork.

The webinar also discussed important issues of excavating tunnels on soft soil, like the effect of regional subsidence. Lastly, it covered why consolidation analysis was done to account for pore pressure reduction through drains.





Midas is presenting on a popular tunnel excavation method
and support system design with our cutting-edge geotechnical 3D software GTS NX.








Speaker :  Angel Francisco Martinez

Category : Geotechnical

Software : midas GTS NX

Date : 2018-11-07
